Home Products MEDIKA 100 ECT-F PLUS



Code MED0103
Small undercounter refrigerator for drugs and vaccines, glass door type and positive temperature range, developped for pharmacies, laboratories, nursing homes, hospitals and private clinics.
+2 / +15°C Temperature range
126 lt (4.45 cu ft) Capacity
52 x 63,5 x 71 cm External dimensions (WxDxH)
ECT-F PLUS Electronic Controller

Undercounter refrigerator for drugs and vaccines, glass door type

The refrigerators for drugs and vaccines series MEDIKA® feature a clean and functional design, with glass door, and adjustable compartments to enhance product storage.

They have been design specifically for the use in pharmacies, hospital wards, physicians', aesthetic medicine, dental and ophtalmologist's practice, laboratories and pharma industries: MEDIKA®  refrigerators comply with international standards in force and answer to the most various requirements, thanks to the vast choice of volume capacities and to the chance of customizing the internal fittings.

The door is made of tempered glass according to safety norm CEI EN 60335-2-89, in antifog crystal, heat-insulating, triple layer for an improved thermal perfomance, with profiles in anodyzed aluminium. The all lenght ergonomic handle guarantees a safe and correct grip. The gasket is magnetic type sealing on all four sides, the automatic lock features a return spring, door stop at 90°, the opening side is reversible

Download Resources

Struttura e refrigerazione

Dimensioni interne: 44 x 51,6 x 42,1 cm

Capacità nominale: 100 lt (3,53 cu ft)

Capacità netta: 96 lt (3,40 cu ft)

Tipo di isolamento: Isolamento in poliuretano espanso iniettato tra le pareti ad altissima densità (43 kg/m3), senza utilizzo di CFC e con iniezione ecologica ad acqua.

Spessore di isolamento: 40 mm.

Struttura: Monoscocca costruita in acciaio plastificato bianco atossico interno/esterno rivestito con speciale trattamento antibatterico certificato, oppure con interno in acciaio inox 18/10 Aisi 304. Angoli arrotondati e fondo a vasca. 4 piedini H=1,5 cm garantiscono la massima stabilità.

Illuminazione interna: Full LED a tutta altezza vano interno

Tipo di refrigerazione: Professionale ventilata

Tipo di sbrinamento: Automatico, adattivo con evaporizzazione acqua di condensa



Temperature display and setting with:  Display resolution: 0,1°C  accuracy ± 0.3°C with backlit 16-character alphanumeric LCD display customizable in 5 languages, keyboard with 4 membrane keys   able to communicate with the user by providing immediate and precise information on the status of the equipment.

It also has a back-up battery for power failure alarm for up to 48 hours, a minimum/maximum temperature recording and potential free contact for remote alarms. Configurable and customizable display in four different reading modes
Keyboard: 4 simple membrane keys allow you to operate by following the intuitive instructions provided by the display. The user has the possibility to customize the password to protect switching on, switching off and changing the set-point and checking alarms even in the event of a power failure.

Alarms: The controller signals different types of temperature alarms, including high temperature alarm due to power failure, and records 12 events, in addition to the minimum and maximum temperature, which can be reset by the user . The dry contact on the board allows to remotely control the alerts.



Refrigerant gas type: R290
Energy consumption: 0,5 kWh/24h
Power absorption/current: kW 0,14 / Amp 0,9
Inrush current: Amp 2,5
Noise level: <40 dBA
Heat rejection/emission EN 12900:  W 20
Shelves max nr.: 2
Wire shelves dimensions: cm 40x49
Drawers max nr.: 3
Inner dimensions of drawers with dividers (LxPxH) (each compartment): cm 10x45x7,5 (3)
Inner dimensions of drawers without dividers (LxPxH): cm 33x45x7,5
